The Switch XG 6 PoE (US XG 6 PoE) is a fully managed switch , mult-gigabit, Layer 3 switch with (4) 10GbE, PoE++ RJ45 ports, (2) 10G SFP+ ports. The switch's networking interface makes it an ideal compliment to the BaseStation XG, Access Point XG, and Access Point SHD. The US-XG-6POE boasts a total non-blocking throughput of 60 Gbps and a switching capacity of 120 Gbps, ensuring efficient data flow across the network even under heavy load. Furthermore, its forwarding rate of 89.3 million packets per second (Mpps) highlights its ability to handle large amounts of traffic with minimal latency.
For power, the switch comes with a 54V DC, 3.88A power adapter and also offers a DC input with a terminal block for wired DC backup power, ensuring continuous operation even in the event of a primary power supply failure. The total available PoE power budget is 170W, providing ample capacity for powering multiple PoE devices.
Management of the switch is facilitated through an Ethernet In-Band interface, along with an RJ45 Serial port and a USB Type C port for Out-of-Band management options. It also features comprehensive ESD/EMP protection to safeguard against electrostatic discharge and electromagnetic pulses, ensuring long-term reliability in a variety of environments.
The switch operates within a temperature range of -5 to 45°C (23 to 113°F) and a humidity range of 5 to 95% non-condensing, making it suitable for deployment in a wide range of indoor environments. For monitoring and management, it includes LED indicators for system status, Ethernet PoE, Link/Speed/Activity, and SFP+ Link/Activity, providing at-a-glance information about the operational status of the switch and connected devices.
Certified by CE, FCC, and IC, the US-XG-6POE meets stringent regulatory standards, ensuring compatibility and safety for deployment in various markets. Its technical specifications and design make it an ideal choice for enterprises looking to expand their network's speed and connectivity while supporting high-powered devices through PoE.
- (1) RJ45 console port
- (4) 10GbE, PoE++ RJ45 ports
- (2) 10G SFP+ ports
- (1) USB-C console ports
- 170W total PoE supply
- Layer 3 switching features
Works with the UniFi Network Application
This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app. The UniFi Network Application is a powerful, enterprise wireless software engine ideal for high-density client deployments requiring low latency and high uptime performance. With its software-based capabilities, the UniFi virtual control plane allows for unlimited scalability under one centralized controller.
Compare with similar products
| | | | |
---|
Ethernet Ports | |
| |
4 x 10 Gbps
| 4 x 10 Gbps
| 8 x 1 Gbps
| 8 x 1 Gbps
|
PoE Out Ports | |
| |
4 x 802.3af (PoE), 802.3at (PoE+), 802.3bt
|
| 1 x Passive PoE
| 4 x 802.3af (PoE)
|
SFP Ports | |
| |
2 x 10G SFP+
| 12 x 10G SFP+
|
|
|
USB Ports | |
| |
1 x USB Type C
|
|
|
|
Management | |
| |
Ethernet
| Ethernet
| Ethernet
| Ethernet
|
Max Power Consumption | |
| |
280 W
| 36 W
| 12 W
| 72 W
|
Operating Temperature | |
| |
-5 °C to 45 °C
| -5 °C to 40 °C
| -5 °C to 45 °C
| -5 °C to 45 °C
|
Dimensions | |
| |
165 x 268.1 x 31.8 mm
| 443 x 221 x 43 mm
| 148.0 x 99.5 x 30.7 mm
| 148.0 x 99.5 x 30.7 mm
|
Weight | |
| |
1.38 kg
| 2.71 kg
| 0.432 kg
| 0.432 kg
|
Mounting Method | |
| |
Tabletop
| RackMount
| Wall Mount, Tabletop
| Wall Mount, Tabletop
|
| | | | |
---|
Ethernet Ports | 4 x 10 Gbps
| 4 x 10 Gbps
| 8 x 1 Gbps
| 8 x 1 Gbps
|
PoE Out Ports | 4 x 802.3af (PoE), 802.3at (PoE+), 802.3bt
|
| 1 x Passive PoE
| 4 x 802.3af (PoE)
|
SFP Ports | 2 x 10G SFP+
| 12 x 10G SFP+
|
|
|
USB Ports | 1 x USB Type C
|
|
|
|
Management | Ethernet
| Ethernet
| Ethernet
| Ethernet
|
Max Power Consumption | 280 W
| 36 W
| 12 W
| 72 W
|
Operating Temperature | -5 °C to 45 °C
| -5 °C to 40 °C
| -5 °C to 45 °C
| -5 °C to 45 °C
|
Dimensions | 165 x 268.1 x 31.8 mm
| 443 x 221 x 43 mm
| 148.0 x 99.5 x 30.7 mm
| 148.0 x 99.5 x 30.7 mm
|
Weight | 1.38 kg
| 2.71 kg
| 0.432 kg
| 0.432 kg
|
Mounting Method | Tabletop
| RackMount
| Wall Mount, Tabletop
| Wall Mount, Tabletop
|
Technical Specs / Datasheet
