The Power of Reyee PoE Switches
The Reyee PoE Switch series is a revolutionary range of network switches explicitly designed for Power over Ethernet (PoE) applications. They provide high-speed, reliable and secure data transmission, while simultaneously powering up PoE-enabled devices like cameras, wireless access points, VoIP phones and other connected devices. Reyee switches are available in different versions, giving you the opportunity to choose the model with the features that will best meet your requirements.
Exceptional Performance and Reliability
Reyee PoE Switches provide an incredibly reliable and efficient network performance, making them ideal for applications across many industries and sectors. The RG-NBS3200 series offers switches with up to 8/24/48 ports and 2-4 SFP ports. Reyee PoE Switches provide robust performance with features such as port security, loop guard and storm control, making them a safe and secure choice for PoE applications.
Advanced Features for Increased Productivity
Reyee PoE Switches are packed with advanced features to ensure optimal performance and increased productivity. The RG-NBS3200 series supports PoE scheduling, PoE Auto Recovery and PoE port setting, as well as PoE surge protection and IEEE802.3at/af detection. By providing these advanced features, Reyee PoE Switches help to reduce network downtime and improve the overall user experience.
Multiple Security Policies to Protect Your Network
Compare with similar products
| | | | |
---|
Ethernet Ports | |
| |
48 x 1 Gbps
| 8 x 1 Gbps
| 24 x 1 Gbps
| 24 x 1 Gbps
|
PoE Out Ports | |
| |
48 x 802.3af (PoE), 802.3at (PoE+)
| 8 x 802.3af (PoE), 802.3at (PoE+)
| 24 x 802.3af (PoE), 802.3at (PoE+)
| 24 x 802.3af (PoE), 802.3at (PoE+)
|
SFP ports | |
| |
4 x 10G SFP+
| 2 x 1G SFP
| 4 x 10G SFP+
| 4 x 1G SFP
|
Switching capacity | |
| |
176 Gbps
| 20 Gbps
| 128 Gbps
| 56 Gbps
|
Forwarding rate | |
| |
130.95 Mpps
| 14.88 Mpps
| 95.24 Mpps
| 41.67 Mpps
|
MAC address table | |
| |
16000
| 8000
| 16000
| 8000
|
Link Aggregation Group (LAG) | |
| |
16
| 8
| 16
| 8
|
ACL | |
| |
1900
| 1200
| 1900
| 1200
|
Max Power Consumption | |
| |
448 W
| 145 W
| 432 W
| 443 W
|
Dimensions | |
| |
440 x 358 x 44 mm
| 330 x 220 x 43.6 mm
| 440 x 357.6 x 43.6 mm
| 440 x 293 x 44 mm
|
Weight | |
| |
5.4 kg
| 2 kg
| 4.75 kg
| 4.5 kg
|
| | | | |
---|
Ethernet Ports | 48 x 1 Gbps
| 8 x 1 Gbps
| 24 x 1 Gbps
| 24 x 1 Gbps
|
PoE Out Ports | 48 x 802.3af (PoE), 802.3at (PoE+)
| 8 x 802.3af (PoE), 802.3at (PoE+)
| 24 x 802.3af (PoE), 802.3at (PoE+)
| 24 x 802.3af (PoE), 802.3at (PoE+)
|
SFP ports | 4 x 10G SFP+
| 2 x 1G SFP
| 4 x 10G SFP+
| 4 x 1G SFP
|
Switching capacity | 176 Gbps
| 20 Gbps
| 128 Gbps
| 56 Gbps
|
Forwarding rate | 130.95 Mpps
| 14.88 Mpps
| 95.24 Mpps
| 41.67 Mpps
|
MAC address table | 16000
| 8000
| 16000
| 8000
|
Link Aggregation Group (LAG) | 16
| 8
| 16
| 8
|
ACL | 1900
| 1200
| 1900
| 1200
|
Max Power Consumption | 448 W
| 145 W
| 432 W
| 443 W
|
Dimensions | 440 x 358 x 44 mm
| 330 x 220 x 43.6 mm
| 440 x 357.6 x 43.6 mm
| 440 x 293 x 44 mm
|
Weight | 5.4 kg
| 2 kg
| 4.75 kg
| 4.5 kg
|
