Ubiquiti UniFi AC Mesh Pro

This item has been discontinued

Manufacturer part number

UAP-AC-M-PRO

Warranty

?
12 months

EAN

0810354024764

We recommend to use the product presented below

Ubiquiti UniFi U6 Mesh Pro
new product

Detailed description

Enhanced Network Resilience

Experience the pinnacle of outdoor wireless connectivity with the UniFi AC Mesh Pro AP, a robust solution crafted for high-performance WiFi networks in expansive open spaces. Encased in shockproof and wear-resistant plastic, this external WiFi access point is built to endure challenging outdoor environments, ensuring durability and consistent performance despite exposure to temperature variations, humidity, and precipitation. Beyond mere resilience, the UniFi AC Mesh Pro uses Mesh technology, which is critical in outdoor settings like large-scale events or sprawling public areas. This technology enables multiple access points to interconnect and form a seamless network, enhancing fault tolerance and facilitating efficient load balancing. Data seamlessly 'hops' from one node to another, ensuring stable connectivity across extensive areas without the need for each node to connect directly to the internet. This mesh setup proves invaluable for managing the connectivity needs of unevenly distributed crowds, providing continuous service even if one node encounters issues.
/images/catalogue/description/411/acmeshprofessional3-6549f64c428fa-1200x1078.jpg
The UniFi AC Mesh Pro also incorporates cutting-edge MIMO 3x3 technology, equipped to handle over 250 simultaneous connections without a hitch. This technology uses three antennas for transmitting and three for receiving data, significantly amplifying network capacity and speed. It delivers impressive throughput rates—up to 450 Mbps on the 2.4 GHz band for broader coverage and up to 1300 Mbps on the 5 GHz band for faster speeds. Such capabilities make the UniFi AC Mesh Pro an essential connectivity hub for high-density environments like summer playgrounds, parks, and outdoor festivals. Moreover, the device offers dual-band performance with combined aggregate speeds of up to 1750 Mbps, ensuring robust support for multiple high-bandwidth applications simultaneously, from streaming high-definition videos to facilitating interactive online events. Enhanced by dual 8 dBi omni-directional antennas, the UniFi AC Mesh Pro extends its reach further and more evenly, delivering 360-degree coverage that penetrates physical barriers and spreads across vast outdoor spaces.
/images/catalogue/description/411/acmeshprofessional4-6549f6548904a-1920x1157.jpg

Powerful Technical Foundation

The UniFi AC Mesh Pro is a formidable outdoor wireless access point, equipped with a built-in radio module that boasts 20 dBm output power and 8 dBi amplification. This potent combination allows it to deliver superior coverage over a radius exceeding 185 meters, making it an exceptional choice for expansive areas like campuses, large industrial zones, or open public spaces. The enhanced signal strength ensures that users receive a reliable and strong WiFi connection, even when located at the outer edges of the coverage area. This access point features two Ethernet ports capable of supporting up to 1000 Mbps bandwidth each, facilitating high-speed connections that are crucial for integrating additional high-demand devices such as video cameras. The primary Ethernet port supports Power over Ethernet (PoE) under the 802.3af standard, which significantly simplifies the installation process. By combining data and power transmission over a single cable, the UniFi AC Mesh Pro eliminates the need for separate power supplies, allowing for a cleaner setup and greater flexibility in device placement.
/images/catalogue/description/411/uapacmpro2-5fa46974923c4.jpeg
Operating under the advanced 802.11 a/b/g/n/r/k/v/ac wireless standards, the UniFi AC Mesh Pro is equipped to handle a wide array of network environments and user demands. It features MIMO technology with 3x3 configurations on both the 2.4GHz and 5GHz bands, providing the capability to manage three data streams simultaneously per band. This MIMO setup enhances network throughput and reliability, supporting more concurrent users and maintaining high performance without degradation, even in high-density settings. Additionally, the UniFi AC Mesh Pro is designed to operate efficiently under extreme environmental conditions, with a durable build that withstands temperatures ranging from -40 °C to 70 °C. Its maximum power consumption of 9W highlights its energy efficiency, making it a cost-effective solution for extensive network deployments. Ethernet management capabilities further enhance the functionality of the UniFi AC Mesh Pro, allowing network administrators to oversee and adjust settings remotely. This includes tasks such as monitoring network traffic, configuring Quality of Service (QoS) settings, and applying security policies, all of which are essential for maintaining the health, efficiency, and security of the network.
/images/catalogue/description/411/uapacmpro1-5fa4695c3aa1d.jpeg

Weatherproof Form Factor

The UniFi AC Mesh Pro is engineered to excel in outdoor environments, featuring a robust weatherproof form factor that ensures its durability and reliability under diverse climatic conditions. Measuring 343.2 x 181.2 x 60.2 mm (H x W x D), its compact and sleek design allows it to integrate seamlessly into a variety of outdoor settings, from parks and sports arenas to outdoor cafes, without detracting from the landscape. This access point is designed to withstand harsh elements, encapsulated in a durable, water-resistant housing that protects against rain, wind, dust, and extreme temperatures. This makes the UniFi AC Mesh Pro an ideal choice for deployment in any outdoor setting where exposure to environmental factors is a concern.
/images/catalogue/description/411/uapacmpro3-5fa469a657ee2.jpeg
Powering the UniFi AC Mesh Pro is highly versatile, supporting several PoE options to cater to different installation scenarios. It can be powered using an 802.3af compatible switch, which supplies power along with data over a single Ethernet cable, simplifying installation by eliminating the need for nearby power outlets. This feature is particularly beneficial in outdoor or remote areas where electrical infrastructure may be limited. Alternatively, the UniFi PoE Switch, part of the broader Ubiquiti Networks UniFi ecosystem, can also power the UniFi AC Mesh Pro. These switches support both 802.3af and the more robust 802.3at (PoE+) standards, the latter offering up to 25.5 watts per port to accommodate more power-intensive devices. Using a UniFi PoE Switch not only ensures efficient power management but also allows for the centralized management of network devices via the UniFi Controller software, enhancing network control and simplification of management tasks. For scenarios where a PoE switch is not available, the included Gigabit PoE adapter offers a convenient alternative. This adapter enables the access point to be powered from any standard electrical outlet, providing flexibility for installations that are isolated or where adding a new device to an existing network setup without existing PoE capabilities.
/images/catalogue/description/411/uapacmpro4-5fa469c70e353.jpeg

UniFi Network Application Integration

Integrated with the UniFi Network Application, this access point forms part of a robust enterprise wireless management system, ideal for environments requiring high-density client deployments. Through the UniFi Network Application, network administrators can efficiently manage multiple networks from a unified interface, streamlining the configuration and monitoring of network devices across various locations. This centralized platform offers real-time network performance insights, enabling administrators to apply configuration changes to multiple networks simultaneously, thereby enhancing operational efficiency.
The application also excels in managing network users and guests, providing tools to create and manage user groups with specific access rights and custom guest portals tailored for different needs. These features ensure appropriate access levels, significantly boosting network security. Additionally, the ability to remotely upgrade device firmware enhances device security and performance across the network by addressing vulnerabilities and updating features without manual intervention. Furthermore, the UniFi Network Application allows for the customization of guest hotspot design, architecture, and privacy settings. Administrators can personalize the login experience, set bandwidth limits, and integrate brand elements, creating a cohesive and controlled guest access environment. Advanced options such as voucher systems are also available to regulate and potentially monetize access. Enhanced privacy controls within the application help in managing data retention and user activity logs, ensuring compliance with privacy regulations. These features, along with the capability to segment network traffic and encrypt user data, bolster both security and privacy for users and guests alike.
/images/catalogue/description/411/swunifinetwork636cdb46b5458838x479-65858ab04466e-838x479.jpg
Adding to its versatility, the mobile app component of the UniFi Network Application facilitates quick device setup and on-the-go management, providing administrators with the flexibility to manage the network remotely. This integration is particularly beneficial in dynamic settings like hotels, educational institutions, offices, and retail spaces, where managing diverse user needs and maintaining stringent security protocols are paramount.

Compare with similar products


Wireless Standard
802.11 a/b/g/n/r/k/v/ac
802.11a/b/g/n/ac
802.11 a/b/g/n/r/k/v/ac
802.11 a/b/g/n/r/k/v/ac
802.11 a/b/g/n/r/k/v/ac
802.11 a/b/g/n/r/k/v/ac
MIMO
2.4GHz 3x3, 5GHz 3x3
2.4GHz 3x3, 5GHz 3x3
2.4GHz 2x2, 5GHz 2x2
2.4GHz 2x2, 5GHz 2x2
2.4GHz 3x3, 5GHz 2x2
2.4GHz 2x2, 5GHz 2x2
2.4GHz Radio Rate
450 Mbps
450 Mbps
300 Mbps
300 Mbps
450 Mbps
300 Mbps
5GHz Radio Rate
1.3 Gbps
1.3 Gbps
867 Mbps
867 Mbps
867 Mbps
867 Mbps
Wireless Antenna Frequency Range & Gain
2.4 - 2.4 (GHz) 8 (dBi), 5.0 - 5.0 (GHz) 8 (dBi)
2.4 - 2.4 (GHz) 3 (dBi), 5.0 – 5.0 (GHz) 3 (dBi)
2.4 - 2.4 (GHz) 1 (dBi), 5.0 – 5.0 (GHz) 2 (dBi)
2.4 - 2.4 (GHz) 3 (dBi), 5.0 – 5.0 (GHz) 3 (dBi)
2.4 - 2.4 (GHz) 3 (dBi), 5.0 – 5.0 (GHz) 3 (dBi)
2.4 - 2.4 (GHz) 3 (dBi), 5.0 - 5.0 (GHz) 4 (dBi)
Antenna range
185 m²
140 m²
25 m²
115 m²
185 m²
140 m²
Ethernet Ports
2 x 1 Gbps
2 x 1 Gbps
3 x 1 Gbps
1 x 1 Gbps
1 x 1 Gbps
1 x 1 Gbps
PoE Out Ports
1 x Passive PoE
Management
Ethernet
Ethernet
Ethernet
Ethernet
Ethernet
Ethernet, Bluetooth
Max Power Consumption
9W
9 W
7 W
6.5 W
6.5 W
8.5W
Operating Temperature
-40 °C to 70 °C
-10 °C to 70 °C
-10 °C to 50 °C
-10 °C to 70 °C
-10 °C to 70 °C
-30 °C to 70 °C
Dimensions
343.2 x 181.2 x 60.2 mm
Ø196.7 x 35 mm
139.7 x 86.7 x 25.75 mm
Ø160 x 31.45 mm
Ø175.7 x 43.2 mm
353 x 46 x 34.4 mm
Weight
0.633 kg
0.450 kg
0.200 kg
0.185 kg
0.315 kg
0.152 kg
Environment
Outdoor
Indoor
Indoor
Indoor
Indoor
Indoor, Outdoor

Wireless Standard 802.11 a/b/g/n/r/k/v/ac
802.11a/b/g/n/ac
802.11 a/b/g/n/r/k/v/ac
802.11 a/b/g/n/r/k/v/ac
802.11 a/b/g/n/r/k/v/ac
802.11 a/b/g/n/r/k/v/ac
MIMO 2.4GHz 3x3, 5GHz 3x3
2.4GHz 3x3, 5GHz 3x3
2.4GHz 2x2, 5GHz 2x2
2.4GHz 2x2, 5GHz 2x2
2.4GHz 3x3, 5GHz 2x2
2.4GHz 2x2, 5GHz 2x2
2.4GHz Radio Rate 450 Mbps
450 Mbps
300 Mbps
300 Mbps
450 Mbps
300 Mbps
5GHz Radio Rate 1.3 Gbps
1.3 Gbps
867 Mbps
867 Mbps
867 Mbps
867 Mbps
Wireless Antenna Frequency Range & Gain2.4 - 2.4 (GHz) 8 (dBi), 5.0 - 5.0 (GHz) 8 (dBi)
2.4 - 2.4 (GHz) 3 (dBi), 5.0 – 5.0 (GHz) 3 (dBi)
2.4 - 2.4 (GHz) 1 (dBi), 5.0 – 5.0 (GHz) 2 (dBi)
2.4 - 2.4 (GHz) 3 (dBi), 5.0 – 5.0 (GHz) 3 (dBi)
2.4 - 2.4 (GHz) 3 (dBi), 5.0 – 5.0 (GHz) 3 (dBi)
2.4 - 2.4 (GHz) 3 (dBi), 5.0 - 5.0 (GHz) 4 (dBi)
Antenna range 185 m²
140 m²
25 m²
115 m²
185 m²
140 m²
Ethernet Ports2 x 1 Gbps
2 x 1 Gbps
3 x 1 Gbps
1 x 1 Gbps
1 x 1 Gbps
1 x 1 Gbps
PoE Out Ports
1 x Passive PoE
Management Ethernet
Ethernet
Ethernet
Ethernet
Ethernet
Ethernet, Bluetooth
Max Power Consumption 9W
9 W
7 W
6.5 W
6.5 W
8.5W
Operating Temperature -40 °C to 70 °C
-10 °C to 70 °C
-10 °C to 50 °C
-10 °C to 70 °C
-10 °C to 70 °C
-30 °C to 70 °C
Dimensions343.2 x 181.2 x 60.2 mm
Ø196.7 x 35 mm
139.7 x 86.7 x 25.75 mm
Ø160 x 31.45 mm
Ø175.7 x 43.2 mm
353 x 46 x 34.4 mm
Weight 0.633 kg
0.450 kg
0.200 kg
0.185 kg
0.315 kg
0.152 kg
Environment Outdoor
Indoor
Indoor
Indoor
Indoor
Indoor, Outdoor
