Teltonika RUTM52 Dual 5G Router

Certified Teltonika Engineers
Official Teltonika Distributor
out of stock
?
872.88
out of stock
?
872.88

Manufacturer part number

RUTM52

Warranty

?
12 months

EAN

4779051842339

Category

Detailed description

Dual 5G Technology

The Teltonika RUTM52 is a state-of-the-art dual 5G router designed for businesses and applications requiring ultra-fast and reliable internet connectivity. Supporting dual 5G modems, it delivers blazing speeds of up to 3.3 Gbps, making it ideal for high-bandwidth applications like video streaming, remote work, and industrial automation. With 4G LTE Cat 20 fallback, the RUTM52 ensures continuous connectivity even when 5G networks are unavailable. Its advanced carrier aggregation capabilities enhance performance by combining multiple bands for maximum throughput. Whether for mission-critical IoT devices or enterprise-level networking, this router sets the standard for next-generation connectivity. Security is at the forefront of the Teltonika RUTM52. The router features advanced VPN protocols, including OpenVPN, IPsec, and WireGuard, for secure remote communication. It also supports robust firewall capabilities and intrusion detection to protect against cyber threats.
/images/catalogue/description/2513/picture1-677fda4d7e5d5-1032x409.jpg

High Performance

The RUTM52 is powered by a robust quad-core ARM Cortex-A53 CPU, ensuring fast data processing and reliable performance. With 5 Gigabit Ethernet ports and dual-band Wi-Fi 6 (802.11ax), it supports simultaneous connections from multiple devices with exceptional speed and stability. The router’s MU-MIMO and Beamforming technologies optimize wireless performance, ensuring low-latency communication and high data rates even in congested network environments. This makes the RUTM52 ideal for offices, large-scale IoT deployments, and smart city applications where consistent and high-performance networking is a must. With Teltonika’s Remote Management System (RMS), users can monitor, configure, and update the router from anywhere, reducing downtime and streamlining network management. The router also includes failover and load-balancing features, ensuring uninterrupted connectivity even in the event of a network disruption.
/images/catalogue/description/2513/picture2-677fdb56dc7a8-1032x409.jpg

Durable Design

Built with industrial-grade durability, the RUTM52 is designed to perform in challenging environments. It operates reliably in temperature ranges from -40°C to 75°C (-40°F to 167°F) and features a rugged metal housing to withstand harsh conditions. The compact design and multiple mounting options make it suitable for deployment in a variety of settings, including remote monitoring, transportation, and energy sectors. Its GNSS (Global Navigation Satellite System) capability provides accurate location tracking, enhancing its suitability for fleet management, logistics, and mobile asset monitoring. The RUTM52 also supports extensive industrial protocols, including Modbus and MQTT, enabling integration with SCADA systems for advanced IoT and industrial automation applications. With its robust design and advanced features, the RUTM52 is perfectly equipped to handle the most challenging networking tasks in industrial and enterprise environments.

Specifications

Mobile Network

Mobile Network Generation

LTE Category

Cat20 - 2.0Gbps/300Mbps
FDD LTE Frequency Bands

1 (2100MHz), 3 (1800MHz), 5 (850MHz), 7 (2600MHz), 8 (900MHz), 20 (800MHz), 28 (700MHz), 32 (1400MHz)
TDD LTE Frequency Bands

38 (2600MHz), 40 (2300MHz), 41 (2500MHz), 42 (3500MHz), 43 (3700MHz)
NR SA Frequency Bands

n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78
NR NSA Frequency Bands

n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78
SIM Card Slot

Mini-SIM, Dual SIM

Wireless Network

Standards

802.11b/g/n/ac

Connectors

RF Connectors

(9) SMA Female, (2) RP-SMA Female

Interfaces

RJ45 Ports

Interface

(1) Digital Input, (1) Digital Output

System Specification

Chipset

MediaTek, Dual-Core, 880 MHz, MIPS1004Kc
RAM

256 MB
Storage Memory

256 MB

Tracking

GNSS

GPS, GLONASS, BeiDou, Galileo, QZSS

Power

Power Method

AC/DC Adapter
Supported Input Voltage

9 - 50 V DC
Max Power Consumption

13 W
Power Connector

4-pin, 3 mm

Physical Parameters

Color

Black
Ingress Protection Code

IP30
Dimensions

132 x 44.2 x 95.1 mm
Weight

0.56 kg
Operating Temperature

-40 °C to 60 °C
Environment

Indoor
Mounting Method

DIN Rail, Wall Mount, Tabletop

Package Contains

External Power Supply

Included
