Ubiquiti UISP Router
Ubiquiti Elite Distributor
in stock
?
-20% 138.67 €
110.42 €
-20% 138.67 €
110.42 €
Ubiquiti Elite Distributor
Detailed description
Gigabit PoE router for MicroPoP applications
Ideal for wireless ISP (WISP) deployments, the UISP™ Router is a fanless PoE router featuring (8) GbE RJ45 ports and (1) 1G SFP port for an additional fiber uplink option. The UISP Router provides a cost-effective routing solution for WISPs looking to quickly and inexpensively deliver Gigabit wireless speeds to their customers. With its hefty 110W total PoE supply, the UISP Router delivers substantial power to every radio in your service network. The UISP Router is managed with the UISP application, a centralized platform where you can monitor and manage all of your UISP devices. The device is fanless and using thermal cooling for silent operation.

UISP application support

Compare with similar products
Ethernet Ports | |||
8 x 1 Gbps | 9 x 1 Gbps | 9 x 1 Gbps | |
PoE Out Ports | |||
8 x Passive PoE | |||
SFP Ports | |||
1 x 1G SFP | 4 x 10G SFP+ | 2 x 10G SFP+ | |
Chipset | |||
Dual-core 880 MHz, MIPS1004Kc | Quad-core ARM® Cortex®-A57 at 1.7 GHz | Quad-core ARM® Cortex®-A57 at 1.7 GHz | |
RAM | |||
512 MB | 4 GB | 4 GB | |
Storage Memory | |||
512 MB | 16 GB | 16 GB | |
Max Power Consumption | |||
10 W | 50 W | 30 W | |
Mounting Method | |||
Tabletop | RackMount, Tabletop | RackMount, Wall Mount |
Ethernet Ports | 8 x 1 Gbps | 9 x 1 Gbps | 9 x 1 Gbps |
PoE Out Ports | 8 x Passive PoE | ||
SFP Ports | 1 x 1G SFP | 4 x 10G SFP+ | 2 x 10G SFP+ |
Chipset | Dual-core 880 MHz, MIPS1004Kc | Quad-core ARM® Cortex®-A57 at 1.7 GHz | Quad-core ARM® Cortex®-A57 at 1.7 GHz |
RAM | 512 MB | 4 GB | 4 GB |
Storage Memory | 512 MB | 16 GB | 16 GB |
Max Power Consumption | 10 W | 50 W | 30 W |
Mounting Method | Tabletop | RackMount, Tabletop | RackMount, Wall Mount |
Technical Specs / Datasheet
Compatible products
Specifications
Interfaces
RJ45 Ports
(8) 1 Gbps
Number of PoE Ports
8 pcs
PoE Out Standards
Passive PoE
SFP Ports
(1) 1G SFP
Management
Ethernet, Bluetooth
System Specification
Chipset
Dual-core 880 MHz, MIPS1004Kc
RAM
512 MB
Storage Memory
512 MB
Power
Power Method
AC/DC Adapter
Power Supply
External AC/DC Adapter
Supported Input Voltage
24 - 28 V DC
Max Power Consumption
10 W
Power Connector
DC Plug 2.1 x 5.5 mm
PSU / POE adapter
27 V DC 4.4 A
Physical Parameters
Color
White
Material
Polycarbonate
Dimensions
210.4 x 95 x 29 mm
Weight
0.600 kg
Operating Temperature
-10 °C to 50 °C
Environment
Indoor
Form Factor
Desktop
Mounting Method
Tabletop
Package Contains
External Power Supply
Included
