MikroTik wsAP ac lite

MikroTik wsAP ac lite

This item has been discontinued

Manufacturer part number

RBwsAP-5Hac2nD

Warranty

?
12 months

EAN

4752224005052

We recommend to use the product presented below

MikroTik wAP ac

MikroTik wAP ac

RBwAPG-5HacD2HnD

Detailed description

In-wall Dual Concurrent 2.4GHz / 5GHz wireless access point with three Ethernet ports and telephone jack pass through for hospitality networks
The wsAP ac lite is a perfect access point (AP) for hospitality networks (hotels, shopping malls, hospitals, airports etc.). It has an unobtrusive case that fits in standard wall power sockets. This way, the unit doesn’t attract attention and blends into any environment.
The wsAP has three Ethernet ports: one on the back side for easy PoE-in, and two LAN ports behind the front door. The device provides Dual concurrent 2.4 GHz and 5 GHz WiFi coverage, it supports 802.11ac, as well as legacy standards. A USB 2.0 port is provided, to charge mobile devices or for storage.
The device also has a pass through telephone jack (RJ11) to connect a desktop phone in a hotel room, for easier cable management. As a separate accessory you can order a special screw set (product code K50), that ensures the bottom door can only be opened by the owner. Mounting bracket fits US and EU most popular telecommunication sockets.

Technical Specs / Datasheet

Technical Specs / Datasheet - MikroTik wsAP ac lite
Quick Start Guide - MikroTik wsAP ac lite

Specifications

Wireless Network

Standards
802.11a/b/g/n/ac
2.4GHz Radio Rate
300 Mbps
5GHz Radio Rate
433 Mbps

Antenna

Wireless Antenna Frequency Range & Gain
2.412 - 2.484 (GHz) 1.5 (dBi), 5.150 - 5.875 (GHz) 3 (dBi)
Beamwidth
360 °
Polarization
Dual Linear

Interfaces

RJ45 Ports
(3) 100 Mbps
Number of PoE Ports
1 pcs
PoE Out Standards
Passive PoE
USB Ports
(1) USB-A 2.0
RJ11 Ports
x1
Management
Ethernet, Wi-Fi

System Specification

Chipset
QCA9531, 1 core, 650 MHz
RAM
64 MB
Storage Memory
16 MB

Power

Power Method
802.3af PoE, 802.3at PoE+
Supported Input Voltage
18 - 57 V DC
Max Power Consumption
20 W

Physical Parameters

Dimensions
126 x 112 x 30 mm
Operating Temperature
-40 °C to 60 °C
Environment
Indoor

Package Contains

External Power Supply
Not Included

Software

MikroTik
RouterOS Level 4
