Brand
Manufacturer part number
R950S
Warranty
?
12 months
EAN
5907772035245
QuRouter 950S
in stock
?
-17% 311.25 €
259.00 €
-17% 311.25 €
259.00 €
Detailed description
QuRouter 950S is a professional industrial LTE Cat 4 & Wi-Fi router for IoT applications. Integrated with omnidirectional LTE and Wi-Fi antennas. This rugged device delivers high performance cellular communication in harsh environments and a wide operating temperature range. The router is equipped with 4G connectivity redundancy through dual SIM failover.
Technical Specs / Datasheet
Specifications
Mobile Network
Mobile Network Generation
2G (GSM), 3G (UMTS), 4G (LTE)
LTE Category
Cat4 - 150Mbps/50Mbps
FDD LTE Frequency Bands
1 (2100MHz), 3 (1800MHz), 7 (2600MHz), 8 (900MHz), 20 (800MHz), 28 (700MHz)
TDD LTE Frequency Bands
38 (2600MHz), 40 (2300MHz), 41 (2500MHz)
SIM Card Slot
Dual SIM
Wireless Network
Standards
802.11b/g/n
2.4GHz Radio Rate
300 Mbps
Antenna
Antenna Design
Dome
Wireless Antenna Frequency Range & Gain
2.4 - 2.5 (GHz) 6 (dBi)
Mobile Antenna Frequency Range & Gain
0.694 - 0.96 (GHz) 2 (dBi), 1.7 - 2.2 (GHz) 2 (dBi), 2.2 - 2.7 (GHz) 4 (dBi)
Beamwidth
35 ° Vertical
Polarization
Vertical
VSWR
< 1.6
Impedance
50 Ω
Interfaces
RJ45 Ports
(4) 100 Mbps
Interface
(1) Digital Input, (1) Digital Output
Management
Ethernet
System Specification
Chipset
Atheros Wasp, MIPS 74Kc, 550 MHz
RAM
128 MB
Storage Memory
16 MB
Power
Power Method
24V Passive PoE
Power Supply
External AC/DC Adapter
Supported Input Voltage
9 - 30 V DC
Max Power Consumption
7 W
Power Connector
4-pin, 3 mm
Physical Parameters
Color
White
Material
Galvanized steel, Aluminium, ABS Plastic
Ingress Protection Code
IP67
Dimensions
160 x 160 x 240 mm
Weight
1.5 kg
Operating Temperature
-40 °C to 75 °C
Environment
Outdoor
Mounting Method
Pole Mount
