QuPanel 5G/LTE Global MIMO 2x2, 5m
new product
new product
in stock
?
142.02 €
142.02 €
Available product variations
Detailed description
QuPanel 5G/LTE Global MIMO 2x2 is directional ultra-wideband 5G outdoor antenna. It is primary designed for LTE/ 5G /3G/ 2G devices which require high efficiency connections. The antenna covers many LTE bands including the new Extended LTE Band 71 and frequencies: 600 - 6000 MHz. The mounting bracket allows installing the antenna on the pole or on the wall as the client antenna. It's ideal solution to use with all industrial and domestic 2x2 5G modems and routers like: Teltonika, DIGI, Mikrotik, Robustel, Cisco, etc.
Supported LTE/4G GSM bands (617-960 MHz): 5, 6, 8, 12, 13, 14, 17, 18, 19, 20, 26, 27, 28, 29, 44, 67, 68, 71, 85, n81, n82, n83, n89.
Supported LTE/4G UMTS bands (1710-2170 MHz): 1, 2, 3, 4, 9, 10, 25, 33, 34, 35, 36, 37, 39, 59, 62, n80, n84, n86, n95.
Supported LTE/4G WCS DARS bands (2300-2400 MHz): 30, 40.
Supported LTE/4G bands (2400-2700 MHz): 7, 38, 41, 53, 69, n90.
Supported LTE/5G bands (3300-3800 MHz): 22, 42, 43, 48, 49, 52, n78.
Technical Specs / Datasheet
Compatible products
Specifications
Mobile Network
Mobile Network Generation
4G (LTE), 5G (NR)
Antenna
Antenna Design
Panel
Mobile Antenna Frequency Range & Gain
0.617 - 0.96 (GHz) 6 (dBi), 1.7 - 2.7 (GHz) 7 (dBi), 3.3 - 4.6 (GHz) 7 (dBi), 4.7 - 6.0 (GHz) 5.5 (dBi)
Beamwidth
80 °
VSWR
< 3
Impedance
50 Ω
Connectors
RF Connectors
(2) SMA Male
Physical Parameters
Material
Aluminium, ABS Plastic, Fiberglass, Polytetrafluoroethylene
Ingress Protection Code
IP67
Dimensions
486 x 292 x 106 mm
Weight
2.8 kg
Operating Temperature
-40 °C to 80 °C
Environment
Outdoor
Mounting Method
Wall Mount, Pole Mount
